Motherboard mounting guide for Open Benchtable and OBT Mini

/in , /by

This is part of our series of how-to & guide about the Open Benchtable and the Open Benchtable Mini. Today we focus on mounting a motherboard on your Open Benchable.

Getting ready

The Open Benchtable is compatible with pretty much all the common form-factors: Mini-ITX, Micro-ATX, ATX, E-ATX and XL-ATX.

The Open Benchtable Mini is compatible with the Mini-ITX (and some Mini-DTX) form factor.

To start, get the number of stand-off that you need from their storage location. ATX & Micro-ATX form factor requires up-to nine and Mini-ITX requires four.

As mentioned in our mounting guides, there are two types of stand-offs and they can be mixed. Half of them are push-pin standoff while the other half is made of screw standoffs (these are similar to the conventional standoffs you find in most cases). All of the standoffs are stored in the feet of your OBT.

If you are using screw standoffs, get the same amount of M3 screws off, there are located on the right of your OBT.

Tips from the team: we usually go for one conventional standoff in the center and push-pins for all of the others! (you can mix push-pin and screw-standoffs that you feel comfortable with).

Motherboard Mounting

Once you’re all set up, install your standoff so they align with your motherboard (green locations).

  • Use the pattern which corresponds to your motherboard

If you are using conventional standoffs, tighten your M3 screws in them to secure the motherboard.

Usign the Open Benchtable Mini is even easier, you only need 4 standoffs

  • OBT Push-pin standoff
    Push-pin standoff
  • OBT Push-pin standoff
    Push-pin standoff
  • OBT screw-in standoff
    Standoff with OBT thumbscrew

Let us know on Social Media what is your favorite mounting strategy: Push-pins only or Mixed ?

Storage mounting guide

/in /by

Even if the OBT is easy to build, sometimes we just want to check how things should be worked out. Today we focus on mounting storage on your OBT.

Getting ready

First, make sure your storage is supported on your OBT model.
The BC1 supports 2.5″ and 3.5″ drives whereas the OBT Mini support 2.5″ drives. What’s not different is that you can attach two drives on each model.

Mounting the drive

Unscrew two M3 screws of you OBT.There are located on the top right corner of the BC1. Concerning the OBT Mini, there are securely held on at the bottom right of the structure.

At the bottom of your OBT are four hard drive slots, align your drive under two of these holes and tighten the M3 screws in your drive’s threads.

Tips from the team: Attach your drive so that its connectors are on the same side that your motherboard’s SATA ports, it will make cabling easier!

Introducing the BC1 Mini, an Open Benchtable for Small Form Factor Systems

/in , /by

The OBT BC1 Mini is a Portable, Lightweight Benchtable Designed Specifically for Small-Form-Factor Testing and Showcasing

October 18, 2017 – The Open Benchtable Project is today delighted to announce the official arrival of the BC1 Mini, a lightweight, toolless benchtable that has been designed specifically for Small Form Factor systems. Co-developed with HWBOT, OverClocking-TV and Streacom, the BC1 Open Benchtable is a community-developed product that has won awards from Red Dot and iF Design in recognition of its portability, esthetics and design prowess. Available in Q4 2017, the BC1 Mini follows the same design principles of the BC1 Open Benchtable, arriving in choice of three colors to match your preference.

Read more

A New Mini Member of the Family: OBT BC1-Mini

/in /by

The Open Benchtable family is about to add a new sibling; the OBT-Mini is taking shape and here is what you need to know about it.

About two years ago the idea to create a lightweight, versatile and portable bench bed took place with the collaboration of Streacom, HWBOT and OverClocking-TV. The following year at Computex the project got a release date; before the end of the summer. After a fast sell out of the first batch of limited Community Edition tables, we recently announced that a new batch is now shipping in silver, black and red colors.

The team is not stopping there and is working on a Mini-ITX sized version based on the successful design of the OBT (also known as BC1). Requests came from user groups in the Small Form Factor Community (SFF) for a small sized bench bed and open air solution. This triggered the creativity of the Open Benchtable design team.

This is our current vision of a Mini-ITX bench bed :

A Mini-ITX Open Benchtable – Tell Us What You Think

These are early pictures of the OBT Mini (BC1 Mini) prototype, which means it is the best time for you to give your feedback on the forum. As of now release date and pricing are unknown.

Want the Open Benchtable for your Micro-ATX, Full-size ATX and big motherboard ? The new batch in red, silver and black are shipping right now (while supply last)!

Order the Original OBT
