Open Benchtable

  • Width
  • 270 mm
  • Length
  • 360 mm
  • Thickness
  • 8 mm
  • Assembled Height
  • 115 mm
  • Weight
  • 1.82 kg

Technical Specifications

Motherboard compatibilityXL-ATX, E-ATX, ATX, Micro ATX, Mini ATX, Mini ITX
Motherboard standoffs height25 mm
Rubber feetYes
Compatibility with fans or radiators (via brackets)240 mm, 140 mm, 120 mm, 92 mm, 80 mm
Storage drive supportYes (up to 2x drives) – 2.5″ and 3.5″
PSU supportYes, ATX 12V / BTX, ATX large and ATX-EPS
PSU weightMaximum 10 kg
Bracket designOriginal
Load capacity25 kg per table / 5 kg spread on two brackets
Material – table100% AL5052 Aluminum (heavy duty)
Table finishSandblasted 80 grain, “white matt”, “black”, “red” anodizing
Material – screws100% SS304 Steel

Inventory

  • Item
  • Manual
  • M3 thumbcrews
  • 6#32 thumbcrews
  • Standoffs
  • Pushpin standoffs
  • PCIe thumbscrews
  • AiO / Fan brackets
  • Traveller protection sleeve
  • Quantity
  • x1
  • x14
  • x6
  • x8
  • x8
  • x4
  • x4
  • x1 (Community edition only)

Open Benchtable Mini

Open Benchtable BC1 Mini Silver Edition
  • Width
  • 190 mm
  • Length
  • 230 mm
  • Thickness
  • 8 mm
  • Assembled Height
  • 78 mm
  • Weight
  • 805 gr

Technical Specifications

Motherboard compatibilityMini ITX
Motherboard standoffs height25 mm
Rubber feetYes (new generation)
Compatibility with fans or radiators (via brackets)170 mm, 140 mm, 120 mm, 92 mm, 80 mm, 60 mm
Storage drive supportYes, up to 2 x 2.5″ drives
Kensington lockYes
PSU supportSFX & SFX-L
PSU weightMaximum 8 kg
Bracket designNew generation
Load capacity15 kg per table / 4 kg spread on two brackets
Material – table100% AL5052 Aluminum (heavy duty)
Table finishSandblasted 80 grain, “white matt”, “black”, “red” anodizing
Material – screws100% SS304 Steel

Inventory

  • Item
  • Manual
  • M3 thumbcrews
  • 6#32 thumbcrews
  • Threaded standoffs
  • Pushpin standoffs
  • PCIe thumbscrews
  • AiO / Fan brackets
  • Quantity
  • x1
  • x8
  • x4
  • x4
  • x4
  • x2
  • x4

Screw Kit

Technical Specifications

CompatibilityOpen Benchtable, Open Benchtable Mini, Streacom BC1, Streacom BC1 Mini
Material100% SS304 Steel

Inventory

  • Item
  • M3 thumbcrews
  • 6#32 thumbcrews
  • Threaded standoffs
  • Pushpin standoffs
  • PCIe thumbscrews
  • Quantity
  • x7
  • x6
  • x4
  • x4
  • x2
